Details

---

Nominal diameter		1 ″ (25A)
Material connection	Inlet	JIS flange 10K 25A equivalent *
	Discharge port
Air connection	Supply port	Rc3 / 8 (with air cock)
	exhaust port	Rc3 / 4 (with muffler) 0
Service air pressure		0.2 to 0.7 MPa
Discharge pressure		0.7MPa
Discharge rate / cycle		Rubber diaphragm type: 600mL
		Fluororesin diaphragm type: 500mL
Slurry limit (maximum passing particle diameter)		3mm or less
Mass		NDP-25BA □: 13.0kg NDP-25BS □: 20.0kg NDP-25BF □: 20.0kg NDP-25BP □: 11.0kg NDP-25BV □: 13.5kg
